An ill wind: The birth of a tornado

Schematic of a supercell thunderstorm.
Schematic of a supercell thunderstorm.

Tornadoes, despite their destructiveness, have a way of inspiring awe and fascination, perhaps in part because they are still shrouded in mystery. Scientists and engineers have been researching them for decades, but we’re still unsure exactly how they form. It’s clear that key ingredients are needed, but even when all are present, it doesn’t guarantee that tornadogenesis—the birth of a tornado—will occur.

Let’s take a step back and talk about thunderstorms for a moment. There are many different flavors of thunderstorms, such as the dry, short-lived storms of the desert southwest, storms with torrential rains in subtropical Florida, or squall lines with damaging winds (sometimes called derechos) in the Midwest. Each type has its own characteristics and lifecycle that differentiates it from other types of storms. However, it’s the “supercell” thunderstorm that is responsible for most tornadoes.

Radar image showing the supercell that produced that Tuscaloosa, AL tornado in April 2011
Radar image showing the supercell that produced that Tuscaloosa, AL tornado in April 2011

Supercells have a deep, strong, rotating updraft (the lifeblood of the storm) called the mesocyclone. Such storms tend to form along frontal boundaries in environments of moderate wind shear, where winds at the surface approach from the south or southeast, and winds aloft come from the west or northwest. There also needs to be ample moisture available for the storm to develop and sustain itself. As the warm, moist air rises, it rotates due to wind shear, and most of the precipitation is pushed ahead of the storm in what is called the forward flank downdraft. A second downdraft (the rear flank downdraft) circulates around behind the storm and interacts with the updraft and inflow air. It’s at this point of interaction that, if conditions align properly, a tornado will form.

The anatomy of a tornado is not well understood, as it’s nearly impossible to take measurements from within. Instead, scientists often depend on mobile Doppler radars, but we are still unable to “see” the tornado at ground-level. Therefore, laboratory simulations are often used to ascertain what’s actually going on inside. These simulations suggest that tornadic flow is quite complex, with upward, downward, and (of course) circulating motions. The largest tornadoes also have multi-vortex structures, with individual rotating funnels that circulate around each other. The few observations that do exist from within tornadoes suggest that they have an “eye” at the center, which has very low pressure: much like a hurricane, but on a much smaller scale. This complex flow and intense very rapid pressure changes are what enable tornadoes to be so destructive compared to hurricanes or straight-line winds.

Simplified schematic of tornado wind flow
Simplified schematic of tornado wind flow
